Features

• Proprietary dorsal attachment sleeve supports effortless addition of personal SRLs
• Plated alloy steel low-profile spring tension roller torso adjusters provide simple adjustment.
• Breathable padded air-mesh shoulder yoke delivers added user comfort
• Paired lanyard parking keepers provide balanced function for single and twin-leg personal SRLs
• Plated alloy steel dorsal D-ring with mating buckle chest and tongue buckle leg closures
• Uncommonly outfitted with 9 grommeted leg adjustment positions for a wider range of fit


Product Specifications

• Webbing: Polyester; 5,000 lb min. static strength
• D-ring: Plated alloy steel; 5,000 lb min. static strength
• Buckles and Adjusters: Plated alloy steel; 3,372 lb min. static strength

Performance Specifications

Static Strength: 3,600 lb min.
ANSI User Capacity: 30 to 310 lb max.
OSHA User Capacity: 130 to 425 lb max.

Sizes & Part Numbers

7016BXS - XS
7016B - UniFit (S, M, L)
7016BX/2X - Dual-size XL/2X
7016B3X - 3X

Downloads
Instruction Manual
Declaration of Conformity
Declaration of Conformity (CSA)
Sell Sheet/Brochure
Harness Sizing Chart

Compliant With:

• CSA Z259.10-2018
• ANSI Z359.11-2021
• OSHA 1926.502 and 1910.66
